Outside Vertical Bends 90˚ (Fixed Wide Angle) H80

Sipariş KoduStok KoduH mmW mmAğırlık (kg/mt)
808-8A PG 01004AA8088APG80801,420
810-8A PG 01004AA8108APG801001,770
812-8A PG 01004AA8128APG801201,825
815-8A PG 01004AA8158APG801501,995
816-8A PG 01004AA8168APG801602,130
820-8A PG 01004AA8208APG802002,240
822-8A PG 01004AA8228APG802252,520
825-8A PG 01004AA8258APG802502,605
830-8A PG 01004AA8308APG803002,970
840-8A PG 01004AA8408APG804004,760
845-8A PG 01004AA8458APG804505,160
850-8A PG 01004AA8508APG805005,560
860-8A PG 01004AA8608APG806006,360
808-8A HDG 01004AA8088AHDG80801,560
810-8A HDG 01004AA8108AHDG801001,950
812-8A HDG 01004AA8128AHDG801202,005
815-8A HDG 01004AA8158AHDG801502,195
816-8A HDG 01004AA8168AHDG801602,345
820-8A HDG 01004AA8208AHDG802002,465
822-8A HDG 01004AA8228AHDG802252,775
825-8A HDG 01004AA8258AHDG802502,865
830-8A HDG 01004AA8308AHDG803003,270
840-8A HDG 01004AA8408AHDG804005,240
845-8A HDG 01004AA8458AHDG804505,680
850-8A HDG 01004AA8508AHDG805006,120
860-8A HDG 01004AA8608AHDG806006,995


1- “A and B” sizes are equal in standard production if required

“B Sizes” can be changed by using reducing parts

2- Please visit page 109 for other radius

3- Different sheet thicknesses can be produced.

4- Please indicate order code and the shape of coating in your orders.


L: Length

T: Thickness

W: Width

PG: Pregalvanized

HDG: Hot Dip Galvanized

Material Thickness and Weight Tolerans: ± 10
